Maximum Gain 52db Moving Magnet, 72db Moving Coil (Volume control adjustable)
Tube compliment: 4 x 6922 tubes (or 6DJ8 or 7DJ8)
Two inputs, one MC with adjustable impedance and one MM
RIAA Accuracy +- .3db
Input Impedance (MM) 47K
Input Impedance (MC) 4 or 40 ohm switched internally (40 with transformer input is ideal for loading 100-1000 ohm specified cartridges; see Art Dudley in September 2007’s Stereophile on why he believes transformers are superior)
Output Impedance 60 ohm
Channel Balance +- .2db
Sensitivity MM 2.5 mv, MC down to .15MV
S/N ratio 68db (ref 2.5mv)
Distortion .2% at 2V
Overload Margin 12V output
Balanced Outputs pin 2 hot (positive phase)
Size 9.25″W, 11.5″D, 4″H
Weight 15 LBs
