No. Of Channels

5.1

No. Of Power Amps

5

Power Output

• 130 watts per channel (6 ohms, 1 kHz, THD 1%, 1ch driven)
• 90 watts per channel (6 ohms, 1 kHz, THD 0.7%, 2ch driven)
• 70 watts per channel (8 ohms,20 Hz - 20 kHz, THD 0.08%, 2ch driven)

Speaker Impedence

4-16 ohms

Input Sensitivity/Impedence

200 mV / 47 kohms

Frequency Response

10 Hz - 100Hz - +1,-3 dB (DIRECT mode)

FM section tuning frequency range

87.5 - 108 MHz

AM section tuning frequency range

522 kHz - 1611 kHz

Power Supply

AC 230 V, 50 Hz

Power Consumption

330 W (Standby 0.1 W, CEC standby 0.5W)

Power Consumption No-Sound

30 W (ECO on), 45 W (ECO off)

Dimensions (W x H x D)

434 x 151 x 319 mm

Weight

7.5 Kg
