Channels
|
7.2
5.2.2
|
|
Power Output per Channel
|
75 W at 8 Ohms / 20 Hz to 20 kHz / 0.08% THD
|
|
DTS Compatibility
|
DTS Neural:X, DTS Virtual:X, DTS-HD Master Audio, DTS:X
|
|
Dolby Compatibility
|
Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Surround, Dolby TrueHD
|
|
Upmixing Technology
|
Dolby Surround, DTS Neural:X, DTS Virtual:X, Dolby Atmos Height Virtualization Technology
|
|
Supported File Formats
|
2.8 MHz DSD, 5.6 MHz DSD, ALAC, FLAC, MP, WAV, WMA
|
|
HDR Compatibility
|
HDR10+, Dolby Vision, Hybrid Log Gamma
|
|
Pass-Through Support
|
8K60p
|
|
Rear A/V Inputs
|
6x HDMI
2x Optical TOSLINK
1x Digital Coaxial
2x Stereo RCA
1x Stereo RCA (Phono MM) with Ground Screw
|
|
Rear A/V Outputs
|
1x HDMI
2x RCA Subwoofer Pre-Out
|
|
Front I/O
|
1x 1/4" / 6.35 mm Headphone Output
1x 1/8" / 3.5 mm Setup Mic Input
1x USB-A Input/Output
|
|
Other Rear I/O
|
1x USB-A (Power) Output
1x RJ45 (Ethernet) Input/Output
1x AM/FM Block Input
|
|
Speaker I/O
|
7x Binding Post Pairs (Front, Center, Rear Surround)
|
|
HDCP Support
|
Yes, Version 2.3
|
|
Audio Return Channel (ARC)
|
ARC, eARC
|
|
Wireless Audio Protocols
|
AirPlay 2, HEOS
|
|
Virtual Assistant
|
Apple AirPlay, Works with Alexa, Works with Google Assistant, Josh.ai, Siri
|
|
Mobile App Compatible
|
Yes: Android & iOS
App Name: Denon AVR Remote
Functionality: Remote Control
|
|
Tuner Type
|
AM, FM
|
|
AC Input Power
|
120 VAC, 60 Hz
|
|
Package Weight
|
23 lb
|
|
Box Dimensions (LxWxH)
|
20.5 x 18 x 8.9"
|
