Technical Information
Number of Power Amps: 11
Power Output
205 watts per channel (6 ohms, 1 kHz, THD:1%, 1 ch driven)
175 watts per channel (6 ohms, 1 kHz, THD:0.7%, 2 ch driven)
140 watts per channel (8 ohms, 20Hz–20kHz, THD:0.05%, 2 ch driven)
Speaker Impedance: 4-16/ohms
Preamplifier Section
Input Sensitivity/ Impedance: 200 mV
Frequency Response: 10Hz–100kHz – +1, -3 dB (Direct Mode)
S/N Ratio: 100 dB (IHF-A weighted, Direct Mode)
FM Section
Tuning Frequency Range: 87.5 - 107.9 MHz
AM Section
Tuning Frequency Range: 520-1710 kHz
General
Power Supply: 120V/60 Hz
Power Consumption: 750W (Standby 0.1W, CEC standby 0.5W)
Power Consumption (No Sound)
65W (ECO Mode On)
110W (ECO Mode Off)
Ports
In
HDMI (Front + 1) x7 + 1
8K HDMI x1
Component (Video) x2
Composite (Video) x4
Phono x1
Analog Audio x6
Digital Coaxial x2
Digital Optical x2
USB Front x1
Out
HDMI Monitor (eARC) x3
8K HDMI x2
Component (Video) x1
Composite Monitor x2
Audio Pre-out (SW) 13.2 ch
Zone Out x3
Headphones x1
Other
Ethernet x1
Microphone Port x1
FM/AM Tuner Antenna x1
Approximate Dimensions:
Without Antenna (WxDxH): 17.1" x 14.9" x 6.6"
Antenna:Horizontal (WxDxH): 17.1" x 15.3" x 6.6"
Antenna:Vertical (WxDxH): 17.1" x 15.3" x 9.3"
Approximate Weight:
Unit: 32 lbs
Shipping: 37.9 lbs
