Amplifier
|
-
Channels:9.4,Object-Based Configuration: 5.1.4,With External Amplifier: 11.4,With External Amplifier: 7.1.4
-
Power Output per Channel:2-Channel Driven:105 W at 8 Ohms / 20 Hz to 20 kHz / 0.08% THD,135 W at 6 Ohms / 1 kHz / 0.7% THD,1-Channel Driven:215 W at 6 Ohms / 1 kHz / 10% THD
|
|
Audio Processing
|
-
DTS Compatibility:DTS Neural:X, DTS Virtual:X, DTS-HD Master Audio, DTS:X
-
Dolby Compatibility:Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
-
Auro 3D Support:Yes
-
Upmixing Technology:Dolby Surround, DTS Neural:X
-
Supported File Formats:2.8 MHz DSD, 5.6 MHz DSD, AAC, ALAC, FLAC, MP3, WAV, WMA via USB
|
|
Video
|
-
HDR Compatibility:HDR10, HDR10+, Dolby Vision, Hybrid Log Gamma
-
Pass-Through Support:8K
-
Upscaling:8K UHD
-
GUI:Yes
|
|
Connectivity
|
-
Rear A/V Inputs:6 x HDMI 2.1,2 x Optical TOSLINK,2 x Digital Coaxial,5 x Stereo RCA,1 x Stereo RCA (Phono MM) with Ground Screw
-
Rear A/V Outputs:2 x HDMI,1 x HDMI Zone 2,1 x 11-Channel RCA Pre-Out,4 x RCA Subwoofer Pre-Out,1 x Stereo RCA Zone 2 Pre-Out
-
Front I/O:1 x USB-A Input/Output,1 x 1/4" / 6.35 mm Headphone Output,1 x 1/8" / 3.5 mm Setup Mic Input
-
Other Rear I/O:2 x Bluetooth/Wi-Fi Coaxial F-Type Input/Output,1 x RJ45 (Ethernet) Input/Output,1 x 1/8" / 3.5 mm (Remote) Input,1 x 1/8" / 3.5 mm (Remote) Output,1 x DE-9 (RS-232C) Input,1 x 1/8" / 3.5 mm (12 V Trigger) Output
-
Speaker Connectors:11 x Binding Post Pairs (Front, Center, Height, Height 2, Rear, Rear Surround)
-
HDCP Support:Version 2.3
-
HDMI Compression Modes:4K120AB / 8K60AB
-
Audio Return Channel (ARC):ARC, eARC
-
HDMI CEC:Yes
-
Media Card Slot:None
-
A/B Speaker Selection:Yes
-
Bi-Amp Capability:Yes
|
|
Wireless Connectivity
|
-
Bluetooth:Yes
-
Wireless Audio Protocols:AirPlay 2, HEOS, Roon Ready, Spotify Connect
|
|
Control
|
-
External Control Support:Android/iOS Control App
-
Virtual Assistant:Apple AirPlay, Works with Alexa, Works with Google Assistant, Josh.ai, Siri
|
|
Power
|
-
Power Consumption:Active: 660 W,No Sound (ECO On): 60 W,No Sound (ECO Off): 100 W,Standby: 0.1 W,CEC Standby: 0.5 W,Network Standby: 2 W
|
|
Physical
|
-
Dimensions (W x H x D):17.1 x 6.6 x 14.9" / 43.4 x 16.8 x 37.8 cm (Antenna Removed),17.1 x 9.3 x 15.3" / 43.4 x 23.6 x 38.9 cm (Antenna Up)
-
Weight:27.6 lb / 12.5 kg
|
|
Packaging Info
|
-
Package Weight:33 lb
-
Box Dimensions (LxWxH):21 x 19.5 x 10.5"
|
