Amplifier
|
-
Channels:15.4,Object-Based Configuration: 9.4.6
-
Power Output per Channel:2-Channel Driven:150 W at 8 Ohms / 20 Hz to 20 kHz / 0.05% THD,190 W at 6 Ohms / 1 kHz / 0.7% THD,1-Channel Driven:260 W at 6 Ohms / 1 kHz / 10% THD
|
|
Audio Processing
|
-
DTS Compatibility:DTS Neural:X, DTS Virtual:X, DTS-HD Master Audio, DTS:X, DTS:X Pro, IMAX Enhanced
-
Dolby Compatibility:Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Surround, Dolby TrueHD
-
Auro 3D Support:Yes
-
Upmixing Technology:Dolby Surround, DTS Neural:X, DTS Virtual:X, Dolby Atmos Height Virtualization Technology
-
Supported File Formats:AAC, ALAC, FLAC, MP3, WAV, WMA
|
|
Video
|
-
HDR Compatibility:HDR10, HDR10+, Dolby Vision, Hybrid Log Gamma
-
Pass-Through Support:8K
-
Upscaling:None
-
GUI:Yes
|
|
Connectivity
|
-
Rear A/V Inputs:7 x HDMI,2 x Optical TOSLINK,2 x Digital Coaxial,5 x Stereo RCA Line,1 x Stereo XLR Balanced Line,1 x Stereo RCA (Phono) with Ground Screw
-
Rear A/V Outputs:2 x HDMI 2.1,1 x HDMI Zone 2,1 x 17-Channel RCA Pre-Out,2 x Stereo RCA Zone 2 / Zone 3 Pre-Out,4 x Mono XLR Subwoofer Pre-Out,4 x RCA Subwoofer Pre-Out
-
Front I/O:1 x USB-A Input,1 x 1/8" / 3.5 mm Setup Mic Input,1 x 1/4" / 6.35 mm Headphone Output
-
Other Rear I/O:1 x AM Block Input,2 x Bluetooth/Wi-Fi Coaxial F-Type Input,1 x RJ45 (Ethernet) Input/Output,2 x 1/8" / 3.5 mm (12 V Trigger) Output,1 x 1/8" / 3.5 mm (Remote) Input,1 x 1/8" / 3.5 mm (Remote) Output,1 x DE-9 (RS-232C) Input,1 x USB-A (Power) Output,1 x NEMA 1-15 (Power) Input
-
Speaker I/O:17 x Binding Post Pairs (Front, Center, Height, Height 2, Rear, Rear Surround)
-
HDCP Support:Version 2.3
-
HDMI Compression Modes:4K120AB / 8K60AB
-
Audio Return Channel (ARC):ARC, eARC
-
HDMI CEC:Yes
-
A/B Speaker Selection:Yes
-
Bi-Amp Capability:Yes
|
|
Wireless Connectivity
|
-
Wi-Fi:Yes
-
Bluetooth:Yes
-
Wireless Audio Protocols:AirPlay 2, HEOS, Roon Ready, Spotify Connect
|
|
Control
|
-
Virtual Assistant:Alexa Built-in, Google Assistant Built-in
|
|
Tuner Section
|
|
|
Power
|
-
Power Consumption:Active: 900 W,No Sound (ECO On): 70 W,No Sound,(ECO Off): 125 W,Standby: 0.1 W,CEC Standby: 0.5 W,Network Standby: 2 W
|
|
Physical
|
-
Dimensions (W x H x D):17.1 x 7.7 x 19.6" / 43.4 x 19.6 x 49.8 cm (Antenna Down),17.1 x 10.2 x 19.4" / 43.4 x 25.9 x 49.3 cm (Antenna Up),17.1 x 7.7 x 19.4" / 43.4 x 19.6 x 49.3 cm (Antenna Removed)
-
Weight:70.5 lb / 32 kg
|
|
Packaging Info
|
-
Package Weight:83.3 lb
-
Box Dimensions (LxWxH):23.5 x 22.5 x 14"
|
